ZOTAC MAGNUS ONE EU27506TC Ultra 7 265 Barebone PC, RTX 5060 Ti 16GB. This is a barebone system. Installed components and supported expansion slots are listed separately below; memory and storage capacities described as supported are not installed capacities.
Configuration
- Intel Core Ultra 7 265 Processor
- No RAM & Storage Included
- GeForce RTX 5060 Ti 16GB GPU
Technical details
| Brand | ZOTAC |
|---|---|
| Model / reference | ZBOX-EU27506TC-BE |
| Processor | Intel Core Ultra 7 265 (20-core, 2.4GHz up to 5.3GHz) |
| Chipset | Intel, NVIDIA |
| System Memory | 2 × DDR5-6400 CSODIMM / DDR5-5600 SO-DIMM slots, up to 96GB |
| Graphics | ZOTAC GAMING GeForce RTX 5060 Ti 16GB GDDR7 |
| Video Output | 1 × HDMI 2.0 (up to 3840 × 2160 @ 60Hz, integrated), 3 × DisplayPort 2.1b (up to 4K 480Hz or 8K 165Hz with DSC), 1 × HDMI 2.1b (up to 4K 480Hz HDR or 8K 120Hz HDR with DSC, Gaming VRR) |
| Maximum Display Support | Up to 4 cloned displays or 6 extended displays |
| 2.5" Drive Bay | 1 × SATA III HDD/SSD bay |
| M.2 Storage | 1 × M.2 NVMe PCIe 5.0 ×4 (2242/2280), 1 × M.2 NVMe PCIe 4.0 ×4 (2242/2280) |
| Card Reader | 3-in-1 UHS-II (SD/SDHC/SDXC) |
| Audio | Microphone/Headphone combo port, 8-channel audio via HDMI |
| USB Ports | 4 × USB 3.2 Gen 2, 4 × USB 3.0 (1 × Type-C) |
| Thunderbolt | 1 × Thunderbolt 4 |
| LAN | Dual LAN (Gigabit Ethernet + 5Gbps Ethernet) |
| Wireless | Wi-Fi 7 (802.11be) |
| Bluetooth | Bluetooth 5.4 |
| Antenna | Dual Wi-Fi SMA connectors |
| Kensington Lock | Yes |
| LED Indicators | Power, HDD, Wi-Fi |
| Power Supply | 500W 80+ Platinum |
| Cooling System | Fan + Heatsink |
| Dimensions (L × W × H) | 270.5 × 126 × 249mm (10.65 × 4.96 × 9.8in) |
| Supported OS | Windows 11 Ready |
| Included Accessories | 2 × Wi-Fi Antennas, Power Cord, USB Flash Drive with OS Drivers, Warranty Card, Quick Start Guide |
