Configuration overview
HPC AMD EPYC 4U Server, 2x AMD EPYC 9655 Processor, 96-Cores & 192-Threads, 512GB (8x 64GB) RAM, 4TB NVMe Gen4, 8x GPU Capability, 2x 10GbE LAN ports, 4x 3200W PSU.
Configuration details
- 2x AMD EPYC 9655 Processor, 96-Cores & 192-Threads, Up to 4.5 GHz Max Boost Clock
- 512GB (8x 64GB) DDR5 5600MT/s
- 4TB NVMe M.2 PCIe Gen 4.0 x4
- 4x 3200W Power Supply
Tech Specs
| Brand | ASUS |
|---|---|
| Model | ESC8000A-E13P |
| Supplier reference | 253289 |
| Product type | Rack server |
| Processor | 2x AMD EPYC 9655 Processor, 96-Cores & 192-Threads, Up to 4.5 GHz Max Boost Clock |
| Memory | 512GB (8x 64GB) DDR5 5600MT/s |
| Storage | 4TB NVMe M.2 PCIe Gen 4.0 x4 |
| Power supply | 4x 3200W Power Supply |
| Processor / System Bus | 2x AMD EPYC 9655 Processor, 96-Cores & 192-Threads, 384 MB Cache, SP5 CPU Socket, Up to 4.5 GHz Max Boost Clock, 400W TDP, DDR5 Memory Type, PCIe 5.0 x128 |
| Memory | 512GB (8x 64GB) DDR5 Desktop Memory, 6400MT/s Speed, CL46 CAS Latency, SK-Hynix Chip Build, 288-Pin, ECC Registered, 1.2 Voltage |
| Expansion Slots | Up to 14 total: |
| Storage | 4TB NVMe M.2 Internal SSD, PCIe Gen 4.0 x4, NVMe 1.3 Interface, 7450 MB/s Sequential Read Speed, 6900 MB/s Sequential Write Speed, 3.3V Voltage, V-NAND 3-bit MLC |
| Networking | 2 x 10GbE LAN (RJ45, X710-AT2), 1 x Mgmt port |
| Front I/O Ports | 1 x Mini DisplayPort, 2 x USB 5Gbps |
| Rear I/O Ports | 1 x USB 5Gbps, 2 x RJ-45 LAN, 1 x RJ-45 Mgmt LAN |
| Switch/LED | Front: Power/Location/Message/Reset/Clear CMOS switches, Q-code LED, LAN/M.2 LEDs |
| Management | ASUS Control Center Enterprise (in-band), ASMB12-iKVM (out-of-band, BMC AST2600) |
| Regulatory Compliance | BSMI, CB, CE, FCC (Class A), RCM |
| Dimensions | 800 x 439.5 x 175 mm (31.5” x 17.3” x 6.9”) |
| Form Factor | 4U |
| Weight | Net: 42 Kg, Gross: 44.23 Kg |
| Power Supply | 3+1 redundant 3200W 80 PLUS Titanium, 20–240V AC, 16A x4, 50/60Hz |
| Environment | Operating: 10°C–35°C |
