Cooler Master V4 Alpha 3DHP Advanced Cooling, Black.
Key specifications
- Fan Speed Front 2050 RPM
- Rear 1850 RPM
- Fan Airflow Front 107.2
- Rear 85.8
- Loop Dynamic Bearing
- Connector 4-Pin
Technical details
| Brand | Cooler Master |
|---|---|
| Model / reference | MAZ-T2HP-217PK-R1 |
| Color | Black |
| Product Name | V4 Alpha 3DHP Black |
| Product Number | MAZ-T2HP-217PK-R1 |
| Exterior Color | Black |
| CPU Socket | AMD® AM5 / AM4 Socket |
| Dimension (L × W × H) | 133 × 114 × 161 mm / 5.2 × 4.5 × 6.3 inch |
| Heat Sink Material | 2 × 3DHP / Aluminum Fins |
| Fan Item | Front / Rear |
| Fan Dimensions (L × W × H) | 120 × 120 × 25 mm |
| Fan LED Profiles | Non-LED |
| Fan Quantity | Front: 1, Rear: 1 |
| Fan Speed | Front: 0–2050 RPM ±10%; Rear: 0–1850 RPM ±10% |
| Fan Airflow | Front: 107.2 m³/h (63.1 CFM); Rear: 85.8 m³/h (50.5 CFM) |
| Fan Pressure | Front: 2.69 mmH₂O; Rear: 1.77 mmH₂O |
| Fan MTTF | >200,000 Hours |
| Fan Noise Level | Front: 22.6 dBA; Rear: 20 dBA |
| Fan Bearing Type | Loop Dynamic Bearing |
| Fan Power Connector | 4-Pin (PWM) |
Before ordering, check the listed socket, connector, voltage and mounting dimensions against your system.
